TPA Motion Control is a prominent enterprise specializing in R&D of linear robots and Magnetic Drive Transport System. With five factories in East, South, and North China, as well as offices in major cities nationwide, TPA Motion Control plays a vital role in the factory automation.
With over 400 employees, including more than 50 dedicated to R&D, TPA is committed to creating products and services that meet market demands while ensuring stable performance and excellent value. The KK series single axis robot produced by TPA are very popular, with models such as KSR, KNR, KCR, and KFR boasting a monthly shipment volume exceeding 5000 sets and a warehouse stock of over 3000 sets.
The distinctive feature of the TPA KK Series(same with THK KR Series, HIWIN KK Series) steel-based single-axis robot lies in its use of internal grinding tracks instead of traditional linear guides. This design not only reduces costs, width, and weight but also enhances the precision of positioning. These precision axes, which can be flexibly configured with adapter to mounting any motor, find widespread applications in increasingly sophisticated automation equipment and production lines.
In response to evolving market demands, TPA introduced the competitive aluminum profile structure KK-E series at the beginning of 2024 to meet customers’ quest for ultimate cost-effectiveness (15% cost savings compared to steel profile) and customization requirements, including non-standard stroke specifications. These lighter-weight modules offer quicker delivery times.
Named the KK-E series, the aluminum Single-Axis Robot currently include KK-60E, KK-86E, KK-100E, and KK-130E models, with additional specifications planned for future release. Here are the key parameters for each model:
KK-60E
Motor Power: 100W
Max Speed: 1000mm/s
Max Stroke: 800mm
Max Payload:
Horizontal: 35kg
Vertical: 7kg
KK-86E
Motor Power: 200W
Max Speed: 1600mm/s
Max Stroke: 1100mm
Max Payload:
Horizontal: 60kg
Vertical: 20kg
KK-100E
Motor Power: 750W
Max Speed: 2000mm/s
Max Stroke: 1300mm
Max Payload:
Horizontal: 75kg
Vertical: 20kg
KK-130E
Motor Power: 750W
Max Speed: 2000mm/s
Max Stroke: 1600mm
Max Payload:
Horizontal: 100kg
Vertical: 35kg
TPA Motion Control excels in innovation, manufacturing capabilities, and rapid response. Whether assisting with product selection or providing comprehensive design solutions, we are dedicated to meeting your needs. Feel free to reach out to us for any product inquiries.
Post time: Sep-24-2024
